. The and the deployment tools create deployable applications by 'freezing' a collection of MATLAB functions and state information into a portable package. Deployed applications run using the MATLAB Component Runtime (MCR), which 'thaws' the functions and state back into executable form. The Compiler creates either standalone executables or shared libraries (DLLs). Many of the differences between MATLAB and the MCR arise because a single user-written application may make use of multiple Compiler-generated shared libraries; in this case the shared libraries share the MCR's global data.

• A Compilation Of Matlab Scripts And Functions For Mac Mac
• A Compilation Of Matlab Scripts And Functions For Mac Download

The MCR differs from MATLAB in five ways. The MCR has no desktop. The MCR only executes encrypted M-files. Global MCR resources, like the Handle Graphics root object and the random number seed, are shared between multiple libraries working together. The M-File and Java paths are fixed and cannot be changed. Certain MATLAB and toolbox features are not available to deployed applications. Because the MCR differs from MATLAB, M-Files written to run using the MCR may sometimes differ from M-Files that run only in MATLAB.

Generally speaking, the differences between MATLAB and the MCR fall into four categories. Compiled applications cannot read, parse, create or manipulate M-files at runtime. The MCR will only execute encrypted M-Files; as a result, all of the M-files in a deployed application are encrypted. MATLAB functions like and will read encrypted M-Files as unintelligible binary data.

Deployed applications cannot, for example, create and then execute M-files at runtime. This will compile, but won't run: fp = fopen( 'Compute.m', 'w'); fprintf(fp, 'function x = Compute(y) n'); fprintf(fp, ' x = y + 17; n'); fclose(fp); rehash; z = Compute(10). Don't rely on the current directory or changes to the MATLAB path to control the execution of M-files. The path of a deployed application is determined at compiled time, and remains forever fixed. The current directory is never on the path in a deployed application.

In the code below, cd-ing to the stringFcns directory does not make stringFcns/add shadow mathFcns/add. The order of these functions at runtime depends on what their order was at compile time. This causes errors: cd mathFcns z = add(x, y); cd./stringFcns s = add(s1, s2). Provide graceful degradation for applications that rely on non-deployable functions. Typically, this means using isdeployed to provide deployable alternatives to non-deployable functions, or at least to issue a precise warning message. Switch (userInput)% There's no editor available to deployed applications;% print a warning message. Case 'EditMFile' if isdeployed warning( 'MyApp:NonDeployable'.

'The editor is not available '. 'in compiled applications.' ); else edit(mfile); end% Deployed applications can't call DOC. But they can% redirect a help query to The MathWorks help site.

Case 'Help' if isdeployed doc(mfile); else web( 'end end Finding Functions at Compile Time In order to produce a deployable package that is smaller than a MATLAB installation, the MATLAB Compiler attempts to narrow the set of deployed functions to only those required by the application. The Compiler calls the MATLAB function to compute the dependent functions of each M-File it compiles. This process differs from the mechanism by which MATLAB determines which functions to call. MATLAB searches for the best match for a function at runtime, when the types of the inputs and the contents of the MATLAB path are known precisely. Depfun analyzes M-files at compile-time, when much less information is available; as a result it may omit functions that your application requires. Functions may be omitted because they are non-deployable or invoked only as callbacks.

Non-deployable Functions Licensing restrictions prevent most design time functions from being compiled or deployed. A design time function is one that changes or augments the basic functionality of a program. Design time functions include the MATLAB editor, most toolbox GUI-based tools, like the function imtool, and functions that create M-Files, like the function.

This code will compile, but won't run: fis,error,stepsize = anfis(trainingData); Attempting to execute non-deployable functions generates MATLAB:UndefinedFunction errors at runtime. Check your application's code to make sure it uses only. Mcc generates a list of excluded functions into a file called mccExcludedFunctions.log. Search this file for the string 'because of compilability rules' to find the non-deployable functions depfun excluded from compilation. Because of the conservative nature of depfun's compile-time analysis, mccExcludedFiles.log may be quite large, and may list functions that your application does not require.

Detecting Dependencies on Callback Functions The MATLAB Compiler's dependency analysis statically analyzes M-file functions to determine what other M-files they depend on. This analysis cannot determine the types of any variables or examine the contents of any strings.

As a result, callback functions, which are often mentioned only in strings, can be overlooked; the Compiler will produce an application that appears to work but which will generate runtime errors when it attempts to invoke the missing callbacks. For example: set(gca, 'ButtonDownFcn', 'LogButtonPress'); If LogButtonPress is not included in the deployed package, this program will fail. Include LogButtonPress by explicitly specifying it on the command line, or inserting a pragma in the M-file that uses LogButtonPress. Specifying a callback using mcc: mcc other options -a dir1/dir2/LogButtonPress.m Using a%#function pragma%#function LogButtonPress Including Functions Called by eval MATLAB's function poses the same kind of problem for the Compiler's dependency analysis that callbacks do: the Compiler cannot examine text strings to determine if they contain function calls. Applications that use eval fail at runtime if the functions invoked by eval are not included in the deployed package. For example, this code that uses eval to create dynamically named MATLAB variables requires the function getdata: for n = 1:count eval(sprintf( 'x%d = getdata(%d);', n, n)); end The solutions to problems created by eval are the same as those for callbacks: use the%#function pragma, or explicitly deploy the function in question by listing it as an argument to your mcc command. Keep Reading I plan to address issues and workarounds surrounding runtime path management, non-supported functions and differences in function behavior in future posts.

In the meantime, you can refer to the documentation for the MATLAB Compiler or post follow-up questions. Published with MATLAB® 7.6. Dan K replied on: 1 of 29 Peter, Thank you for addressing an area which has long represented a headache for me. I do have a few questions though: 1. Could you give a somewhat more complete definition of a 'non-constant static state'?

You give the example of a global variable, but what else falls into this category? I've never understood why the necessity exists for explicitly coding in the deployprint instead of print.

If print doesn't exist in compiled code (which I also don't understand the reasons for), can't the compiler recognize this and do the substitution at compile time? I find that having to include many variations based on isdeployed makes the code much more difficult to maintain and comprehend. Can you talk about the issues associated with UNC paths? One perpetual challenge for me is that I deploy software to many users on a windows network, where everybody needs to be able to access the same directory on the server.

Unfortunately, different computers have the server mapped differently, so I can't use drive letters. The best I've been able to do is apply a system call to ('net use') and then parse it for certain key words (which is kludgy, at best). Is there a prefered method for dealing with this sort of thing?

Peter Webb replied on: 2 of 29 Dan, In response to your questions: 1. By non-constant static state, I mean global data that the program both reads and writes. State that gets initialized once and is then 'read only' is OK. Multiple instances of the MCR can inadvertently share state through:.

The HG root. Java global state (for example, Java singleton objects). The properties of a figure window, like UserData: set(1, 'UserData', 25). MATLAB Singleton objects. Compiled applications must use DEPLOYPRINT on Microsoft Windows because of a difference in the way they display figure windows. Compiled applications render their graphics into Java frames. MATLAB's printing relies on access to the native (i.e., Microsoft Windows) graphical data, which is not available in compiled applications.

Therefore, since compiled applications render their graphics differently, they must print differently as well. The compiler can't substitute one call for another at compile time because that would require modifying the M-file in question, which we don't do as a matter of policy.

Regarding UNC paths, I think probably the best solution is to use identical drive letters; failing that, your solution (which works:-)) seems OK. I don't know of any other 'best practices,' in this area. OkinawaDolphin replied on: 4 of 29 I would like to ask a question concerning global variables: If two compiled programs that run on the same computer use global variables with the same name, does the MCR assume that they are the same? Actually I have run two different compiled programs on the same computer and both used (and are still using) a global variable. They have the same name in both programs.

In both programs the global variables contain a connection to the same database. Program 1 runs continuously. Program 2 is called seldomly and closed after a short time. Program 2 clears its own global variable when being closed. Program 1 still operates properly. Also, program 2 creates initializes its global variable only if it is empty. If program 2 accessed the global variable of program 1, program 2 would never ever function.

However, program 2 operates as expected. These programs are very different from each other. Was it just luck that both programs worked properly? I used R2007a when compiling the two programs. Will problems occur when switching to R2008a or R2008b? Peter Webb replied on: 7 of 29 Rodney, The side-effect you noticed with regard JAVAADDPATH clearing global variables is one of the reasons we don't recommend the use of JAVAADDPATH in compiled applications. Some of the commands that manipulate the path might seem to work at first, but they almost always have some unintended side effects.

And besides, changing the path sort of violates the model of a deployed application: once compiled, an application is not supposed to 'change' - there should be no way to run new code, or modify the application's functionality. Peter Webb replied on: 8 of 29 OkinawaDolphin, The only way that two or more compiled applications can communicate with (or affect) one another is through the filesystem.

For example, one application could write a file that another could read. However, compiled shared libraries can affect one another via interactions through shared global state (such as the Handle Graphics root object) if they are both linked into the same executable. So, if your program 1 and program 2 are independent executables, they will maintain their global variables completely separately, and you should have no problems. This behavior is not scheduled to change in any upcoming release. Peter Webb replied on: 16 of 29 Stephen, Compiled MATLAB applications are similar to Java programs and.NET assemblies. All three of these kinds of applications require relatively large virtual machines to run them: Java applications need the JVM,.NET assemblies require the CLR and MATLAB applications need the MCR.

That architecture does not lend itself to single file solutions. You could, of course, package the MCR with each of your executables or shared libraries, and each of your users could install it locally. You might also be able to install the MCR locally on your machine and then share the installation directory across your internal network. There is currently no way to build a single binary that contains all the code required for a MATLAB Compiler-generated application; we don't support static linking because of the inefficiencies it creates.

Tom M replied on: 17 of 29 I'm still somewhat confused and unfortunately have only limited access to the Compiler Toolbox so cannot simply guess-and-check-and-learn. So here goes: 1.

My startup.m has an addpath call in it. When I build a project that calls a function that lives only in the directory that I've added, will the depfun magic find that function and add it to the mcc command-line? I know I can explicitly add it to the build command with either '-a' or by dropping the file into the 'Other files' part of the deploytool, but my question is why the compiler can't grab the function at compile-time and automatically include it in the executable. (It seems that it can't.) If I just included the path with a '-I' would it work?

A Compilation Of Matlab Scripts And Functions For Mac Mac

I understand the compiler has to 'freeze' the M-code at compile-time, and can't use the path at run-time to dynamically locate and run new M-code sitting somewhere on disk. My question has to do with the 'right' way to link in code from a library that I use across many projects. Do I have to '-a' every M-file in the library? What do I need to do so that I can rely on depfun to pick up the right functions (and maybe only those that it needs) with as little intervention as possible? Similarly: It's only the state of the path at compile-time that matters, right?

So both me and the compiler should/do ignore any addpath and rmpaths in the code that is to be compiled. A different topic: We've seen some evidence that use of 'disp' a lot on in a stand-alone compiled application slows it down considerably, compared to running from the MatLab command-line. Turning off all disp statements makes a remarkable improvement. Haven't tried something like fprintf instead yet. Does this make sense?

Or is something else going on? (Windows I/O buffering is mis-tuned, we're idiots,.?) 4.

Someone ('Dan K', above) mentioned 'issues with UNC paths' but I didn't understand what was wrong with actually using UNC paths. We've just started doing this across a Windows network and it seems to work. This way we avoid the use of drive letters, which can be user- and logon-state- dependent. So why not use them.? Thanks for helping clarify some very important points already, -tom.

Peter Webb replied on: 18 of 29 Tom, 1. Using ADDPATH in a startup.m file is generally not a good way to manage the use of libraries of M-files in compiled applications. Some alternatives:.

MCC's -a switch (as you noted above). Using a bundle file to automate the inclusion of -a switches on the MCC command line. See the Compiler's documentation. Use ADDPATH in an interactive MATLAB session and then save the path (via SAVEPATH). This permanently modifies the MATLAB path, and therefore the path used by MCC. Yes, the state of the path at COMPILE TIME is what matters.

Any addpath/rmpath calls in the compiled code will have no effect on what gets included in the deployed application (though they may cause runtime errors for the deployed application, as indicated in the main body of this posting). I'm not sure why the use of disp should affect performance. This bears further investigation. R2007b enhanced MATLAB's support for UNC paths, thereby masking the underlying problem: Microsoft DOS commands do not uniformly support UNC paths. MATLAB commands that use DOS commands cannot support UNC paths either. In MATLAB, cd to a UNC directory and then execute system('dir'); this command will fail because DOS doesn't support DIR when the current directory is a UNC path. Tim Doyle replied on: 19 of 29 Regarding the distribution of the compiled code and the MCR.

It is my understanding that the 'deploytool' GUI (which is new to R2008a??) creates a single install program for the compiled code written by the user AND the MCR. Thereby eliminating the need to distribute the MCR separately to the compiled code. Is this correct? By the way the spam protection asking me the sum of 3 + 9 seems to think 12 is not the right answer!!! I've had to refresh to get a new question. Carl Wouters replied on: 21 of 29 Hi, very nice posts!! But there is something that no one ever talks about when they are talking about the compiler.

At work we are making our own toolbox and we use ofcourse packages for this and object oriented structures. As a test we tried with a trial version to compile a specific function that ofcourse needs different functions that are in different packages in the same main root folder. This didn't work. I have been looking a while now for some information about this, without any luck. So my question: Is it possible to compile a function that uses functions embeded in different packages?

I thank you in advance, Carl. Hooman replied on: 24 of 29 Loren, I have two folders which includes two DLL libraries.

A Compilation Of Matlab Scripts And Functions For Mac Download

These two use other DLL libraries. Let's call the folders F1 and F2. Folder F1 contains DLL1 with all of its required DLLs.

Folder F2 include DLL2 with all of its required DLLs. In my M file in GUI OpeningFcn I add assembly as follows: NET.addAssembly(strcat(ctfroot,' F1 DLL1.dll')); NET.addAssembly(strcat(ctfroot,' F2 DLL2.dll')); The program is running on my machine in MATLAB. The MCR is set up properly on the destintation machine. ( It runs other compiled files. ) I have put F1 and F2 in the program filesMATLAB2010b, and included them in the Compiler for packaging. However, when we click on exe file in the destination machine I hear a beep and the program does not run. I have spoken to tech support and they referred me to one of your pages, which has taken my program to this point.

What is it that I am missing? Richard de Garis replied on: 25 of 29 Peter, or Loren, I'm finding the relative ease of working with Matlab scripts to open/close excel files, read/write from/to them, etc. Is rapidly turning into a headache in terms of deploying equivalent functions, for other people to use. I've already discovered that I can't access the current Excel process directly through actxGetRunningServer, because the request to Excel for its process handle never gets answered because Excel itself is waiting for the called Matlab function to complete. Now, the wonderful global workspace doesn't directly translate across to deployment space.

Regarding your recommendation to use a handle object, I have no experience creating & using objects. Do I simply declare a methodless class and stick all the data in the properties section, like.

Isaiah replied on: 28 of 29 Peter, One of my matlab users received this error could you give me some insight. mcc -m -v s2punwrap.m Warning: DOS programs may not execute correctly when the current directory is a UNC pathname. 'theUNCpath' CMD.EXE was started with the above path as the current directory. UNC paths are not supported. Defaulting to Windows directory. You do not have write permission in the output directory: 'C: Windows'.???

Error using mcc Error executing mcc, return status = 1 (0x1). Peter Webb replied on: 29 of 29 Isaiah, Sounds like they were running the MATLAB Compiler in a path that looks like server directory. The MATLAB Compiler doesn't like UNC paths as outputs (it can't open files on UNC paths reliably) so it decided to use the standard Windows directory as output. However, the user did not apparently have write permission to that directory, so compilation failed.

Solution: The user should map the UNC path to a drive letter and cd to that drive letter from inside MATLAB before starting MCC.
